USEFUL INFORMATION
ICC

The International Chamber of Commerce (ICC) is the largest, most representative business organization in the world. Its over 45 million members in over 100 countries have interests spanning every sector of private enterprise.

ICC has three main activities: rule setting, dispute resolution, and policy advocacy. Because its member companies and associations are themselves engaged in international business, ICC has unrivalled authority in making rules that govern the conduct of business across borders. Although these rules are voluntary, they are observed in thousands of transactions every day and have become part of international trade.

ICC
INCOTERMS
INCOTERMS

The Incoterms or International Commercial Terms are a series of pre-defined commercial terms published by the ICC relating to International Commerce Law.

INCOTERMS are not only useful for traders in different countries to understand one another but also make international trade easier.
These trade standard definitions that are most commonly used in international contracts are protected by ICC copyright.

CONTAINER SPECIFICATION




20’ Dry Freight Container

  •  L20’ x W8’ x H8’6”
    •    Usage: General Cargo

Interior Dimensions

5,919mm (L) x 2,340mm (W) x 2,380mm (H)

Door Opening

2,386mm (W) x 2,278mm (H)

Tare Weight

4,189 lbs – 1,900 kg

Cubic Capacity

1,165 cuft – 33.0 cbm

Pay Load

48,721 lbs – 22,100 kg

20’ Open-Top Container

  •  With removable door header - L20’ x W8’ x H8’6”
    •    Usage: Out-Of-Gauge Cargo (Mainly Over-Height)

Interior Dimensions

5,919mm (L) x 2,340mm (W) x 2,286mm (H)

Door Opening

2,286mm (W) x 2,251mm (H)

Top Opening

5,425mm (L) x 2,222mm (W)

Tare Weight

4,793 lbs – 2,174 kg

Cubic Capacity

1,116 cuft – 31.6 cbm

Pay Load

48,1117 lbs – 21,826 kg

20’ Reefer Container (Refrigerated Container)

  •  L20’ x W8’ x H8’6”
    •    Usage: Cargo Requiring Controlled Temperature Settings

Interior Dimensions

5,428mm (L) x 2,266mm (W) x 2,240mm (H)

Door Opening

2,286mm (W) x 2,188mm (H)

Tare Weight

6,482 lbs – 2,940 kg

Cubic Capacity

971 cuft – 27.5 cbm

Pay Load

53,043 lbs – 24,060 kg

20’ Flatrack Container

  •  L20’ x W8’ x H8’6” (High Bed)
    •    Usage: Cargo with Out-of Gauge Dimension (Mainly Over-Height & Over-Width)

Interior Dimensions

5,662mm (L) x 2,438mm (W) x 2,327mm (H)

Tare Weight

5,578 lbs – 2,350 kg

Pay Load

47,333 lbs – 21,470 kg

20’ Open-Top / Open-Side Container

  •  With removable tarpaulin at top and sides : L20’ x W8’ x H8’6”
    •    Usage: Cargo with Out-of Gauge Dimension (Mainly Over-Height)

Interior Dimensions

5,928mm (L) x 2,318mm (W) x 2,259mm (H)

Door Opening

2,236mm (W) x 2,278mm (H)

Top Opening

5,352mm (L) x 2,118mm (W)

Tare Weight

6,118 lbs – 2,775 kg

Cubic Capacity

1,095 cuft – 31.0 cbm

Pay Load

46,792 lbs – 21,225 kg

20’ Collapsible Flatrack Container

  •  L20’ x W8’ x H8’6”
    •    Usage: Cargo with Out-of Gauge Dimension (Mainly Over-Height & Over-Width)

Interior Dimensions

5,946mm (L) x 2,126mm (W) x 2,233mm (H)

Tare Weight

6,393 lbs – 2,900 kg

Pay Load

59,745 lbs – 27,100 kg

40’ Dry Freight Container

  •  L40’ x W8’ x H8’6”
    •    Usage: General Cargo

Interior Dimensions

12,045mm (L) x 2,309mm (W) x 2,379mm (H)

Door Opening

2,289mm (W) x 2,278mm (H)

Tare Weight

6,799 lbs – 3,048 kg

Cubic Capacity

2,377 cuft – 67.3 cbm

Pay Load

60,397 lbs – 27,396 kg

40’ Open-Top Container

  •  With removable door header - L40’ x W8’ x H8’6”
    •    Usage: Out-Of-Gauge Cargo (Mainly Over-Height)

Interior Dimensions

12,043mm (L) x 2,309mm (W) x 2,379mm (H)

Door Opening

2,279mm (W) x 2,278mm (H)

Top Opening

11,585mm (L) x 2,162mm (W)

Tare Weight

9,480 lbs – 4,300 kg

Cubic Capacity

2,260 cuft – 64.0 cbm

Pay Load

57,720 lbs – 26,181 kg

40’ Flatrack Container

  •  L40’ x W8’ x H8’6”
    •    Usage: Cargo with Out-of Gauge Dimension (Mainly Over-Height & Over-Width)

Interior Dimensions

12,080 (L) x 2,438(W) x 2,103(H)

Tare Weight

12,081 lbs – 5,480 kg

Pay Load

55,115 lbs – 25,000 kg

40’ Dry High-Cube Container

  •  L40’ x W8’ x H9’6”
    •    Usage: General Cargo

Interior Dimensions

12,056mm (L) x 2,347mm (W) x 2,684mm (H)

Door Opening

2,340mm (W) x 2,585mm (H)

Tare Weight

6,393 lbs – 2,900 kg

Cubic Capacity

2,684 cuft – 76.0 cbm

Pay Load

65,256 lbs – 29,600 kg

40’ Dry High-Cube Reefer Container

  •  L40’ x W8’ x H9’6”
    •    Usage: Cargo Requiring Controlled Temperature Settings

Interior Dimensions

11,628mm (L) x 2,294mm (W) x 2,509mm (H)

Door Opening

2,290mm (W) x 2,535mm (H)

Tare Weight

9,766 lbs – 4,430 kg

Cubic Capacity

2,363 cuft – 66.9cbm

Pay Load

61,883 lbs – 28,070 kg

40’ Collapsible Flatrack Container

  •  With 4 corner posts foldable - L40’ x W8’ x H8’6”
    •    Usage: Cargo with Out-of Gauge Dimension (Mainly Over-Height & Over-Width)

Interior Dimensions

12,080mm (L) x 2,126mm (W) x 2,043mm (H)

Tare Weight

12,787 lbs – 5,800 kg

Pay Load

64,374 lbs – 29,200 kg

45’ High-Cube Dry Container

  •  L45’ x W8’ x H9’6”
    •    Usage: General Cargo

Interior Dimensions

13,102mm (L) x 2,347mm (W) x 2,690mm (H)

Door Opening

2,290mm (W) x 2,535mm (H)

Tare Weight

8,598 lbs – 3,900 kg

Cubic Capacity

3,026 cuft – 85.7 cbm

Pay Load

63,052 lbs – 28,600 kg

40’ High-Cube Reefer Container

  •  L40’ x W8’ x H9’6”
    •    Usage: Cargo Requiring Controlled Temperature Settings

Interior Dimensions

13,102mm (L) x 2,294mm (W) x 2,509mm (H)

Door Opening

2,290mm (W) x 2,535mm (H)

Tare Weight

11,464 lbs – 5,200 kg

Cubic Capacity

2,663 cuft – 75.4 cbm

Pay Load

60,186 lbs – 27,300 kg
